Mitsubishi Electric Trane® MSZ-GL09NA-U2 MSZ-GL09NA-U2
  1. pin-int

Mitsubishi Electric Trane® MSZ-GL09NA-U2 MSZ-GL09NA-U2

Mitsubishi Electric Trane® MSZ-GL09NA-U2 Air Conditioner Indoor Unit, 208/230 V, 1 A, 1 ph-Phase, Wall Mounting

  • Manufacturer: Mitsubishi Electric Trane HVAC US LLC
  • Brand Name: Mitsubishi Electric Trane®
  • Part Number: MSZ-GL09NA-U2
  • MPN: MSZ-GL09NA-U2
  • Min. Order Qty: 1
  • Qty. Interval: 1
    • Sign In for Availability

Mitsubishi Electric Trane® Air Conditioner Indoor Unit, 208/230 V, 1 A, 60 Hz, 1 ph Phase, 9000 Btu/hr Cooling, 10900 Btu/hr Heating, 145 cfm, R-410A Refrigerant, 43 dBA Cooling, 43 dBA Heating Sound Level, Wall Mounting, Munsell 1.0Y 9.2/0.2, 80 to 95 deg F Cooling, 47 to 70 deg F Heating, 31-7/16 in Overall Length, 9-1/8 in Overall Width, 11-5/8 in Overall Height, Additional Information: 1/4 in Liquid Line Size, 3/8 in Suction Line Size

Additional Information      :      1/4 in Liquid Line Size, 3/8 in Suction Line Size
Amperage Rating      :      1 A
BTU Rating      :      9000 Btu/hr Cooling, 10900 Btu/hr Heating
CFM Rating      :      145 cfm
Color      :      Munsell 1.0Y 9.2/0.2
Frequency Rating      :      60 Hz
Mounting Type      :      Wall
Overall Height      :      11-5/8 in
Overall Length      :      31-7/16 in
Overall Width      :      9-1/8 in
Phase      :      1 ph
Refrigerant Type      :      R-410A
Sound Level      :      43 dBA Cooling, 43 dBA Heating
Temperature Rating      :      80 to 95 deg F Cooling, 47 to 70 deg F Heating
Voltage Rating      :      208/230 V
  • Slim wall-mounted indoor units provide zone comfort control
  • The outdoor unit powers the indoor unit, and should a power outage occur, the system is automatically restarted when power returns
  • Multiple fan speed options: Quiet, Low, Medium, High, Super-high, Auto
  • Multiple control options available - Hand-held Remote Controller (provided with unit)
  • kumo cloud® smart device app for remote access
  • Third-party interface options
  • Wired or wireless controllers
  • Hot-Start Technology: no cold air rush at equipment startup or when restarting after Defrost Cycle
  • Quiet operation
  • Smart Set: recalls a preferred preset temperature setting at the touch of a button
  • pdfInstruction/Installation Manual https://assets.unilogcorp.com/267/ITEM/DOC/Mitsubishi_Electric_Trane_MUY_GL15NA_U2_DAM_Instruction_Installation_Manual.pdf
  • pdfService Manual https://assets.unilogcorp.com/267/ITEM/DOC/Mitsubishi_Electric_Trane_MSY_GL09NA_U2_Service_Manual.pdf
  • pdfSubmittal https://assets.unilogcorp.com/267/ITEM/DOC/Mitsubishi_Electric_Trane_MSZ_GL09NA_U2_Submittal.pdf
