Mitsubishi Electric MUZ-GX24NL MUZ-GX24NL
Mitsubishi Electric MUZ-GX24NL Ductless Mini-Split Heat Pump Outdoor Unit, 208/230 V, 0.76 A, 22400 Btu/hr Cooling
- Manufacturer: Mitsubishi Electric Corporation
- Brand Name: Mitsubishi Electric
- Part Number: MUZ-GX24NL
- MPN: MUZ-GX24NL
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
Mitsubishi Electric Ductless Mini-Split Heat Pump Outdoor Unit, 208/230 V, 0.76 A, 1720 W Cooling, 2340 W Heating, 60 Hz, 1 ph, 27600 Btu/hr Heating, 22400 Btu/hr Cooling, 1934 cfm Heating CFM Rating, 2202 cfm Cooling CFM Rating, 13 EER Rating, 21.5 SEER, 10.3 HSPF, Flared Connection, Twin Rotary Compressor, R-454B Refrigerant, 1/4 in Liquid Line, 5/8 in Suction Line, 25 A Fuse Rating, 55 dBA Heating Sound Level, 55 dBA Cooling Sound Level, Wall Mounting, Finish: Munsell 3Y 7.8/1.1, -5 to 75 deg F Heating Operating Temperature, 14 to 115 deg F Cooling Operating Temperature, 13 in Overall Length, 33-1/16 in Overall Width, 34-5/8 in Overall Height
| Amperage Rating | : | 0.76 A |
| Compressor Type | : | Twin Rotary |
| Connection Type | : | Flared |
| Cooling BTU Rating | : | 22400 Btu/hr |
| Cooling CFM Rating | : | 2202 cfm |
| Cooling Operating Temperature | : | 14 to 115 deg F |
| Cooling Sound Level | : | 55 dBA |
| EER Rating | : | 13 |
| Finish | : | Munsell 3Y 7.8/1.1 |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 25 A |
| HSPF Rating | : | 10.3 |
| Heating BTU Rating | : | 27600 Btu/hr |
| Heating CFM Rating | : | 1934 cfm |
| Heating Operating Temperature | : | -5 to 75 deg F |
| Heating Sound Level | : | 55 dBA |
| Liquid Line Size | : | 1/4 in |
| Mounting Type | : | Wall |
| Overall Height | : | 34-5/8 in |
| Overall Length | : | 13 in |
| Overall Width | : | 33-1/16 in |
| Phase | : | 1 ph |
| Power Rating | : | 1720 W Cooling, 2340 W Heating |
| Refrigerant Type | : | R-454B |
| SEER Rating | : | 21.5 |
| Suction Line Size | : | 5/8 in |
| Voltage Rating | : | 208/230 V |
- Blue Fin Coating: An anti-corrosion treatment applied to the aluminum fins of the heat exchanger of the outdoor unit to protect against corrosion caused by salt, sulfur, and other airborne contaminants, especially in coastal and industrial areas
- INVERTER-driven compressor: An inverter-driven compressor generates the precise capacity needed to maintain a temperature set point
- Powered by Outdoor Unit: The outdoor unit powers the indoor unit, and should a power outage occur, the system is automatically restarted when power returns
Instruction/Installation Manual
