LG HVAC Ductless Multi-Split Heat Pump, Multi_MAX Series, 208-230 V, 32.7 A, 60 Hz, 1-Phase, 58000 Btu/hr Heating, 50500 Btu/hr Cooling, 1942 cfm Heating CFM Rating, R1 Scroll Compressor, R-410A Refrigerant, 3/8 in Liquid Line, 3/4 in Suction Line, 40 A Fuse Rating, Direct Drive, Tonnage: 4.5 ton, 55 dB Heating Sound Level, 53 dB Cooling Sound Level, -4 to 64 deg F Heating Operating Temperature, 14 to 118 deg F Cooling Operating Temperature, 13 in Overall Length, 37-13/32 in Overall Width, 54-11/32 in Overall Height
| Amperage Rating | : | 32.7 A |
| Compressor Type | : | R1 Scroll |
| Cooling BTU Rating | : | 50500 Btu/hr |
| Cooling Operating Temperature | : | 14 to 118 deg F |
| Cooling Sound Level | : | 53 dB |
| Drive Type | : | Direct |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 40 A |
| Heating BTU Rating | : | 58000 Btu/hr |
| Heating CFM Rating | : | 1942 cfm |
| Heating Operating Temperature | : | -4 to 64 deg F |
| Heating Sound Level | : | 55 dB |
| Liquid Line Size | : | 3/8 in |
| Overall Height | : | 54-11/32 in |
| Overall Length | : | 13 in |
| Overall Width | : | 37-13/32 in |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| Series | : | Multi_MAX Series |
| Suction Line Size | : | 3/4 in |
| Tonnage | : | 4.5 ton |
| Voltage Rating | : | 208-230 V |
- R1 Scroll (Variable Speed) Compressor
- Auto operation
- Auto restart
- Self diagnosis
- Defrost/Deicing
- Low ambient cooling down to 14degF
- Soft start
- Restart delay (three [3] minutes)
Specification Sheet
