Ducane™ 92G1DF070BE12 CON 92G1DF070BE12
Ducane™ 92G1E Series 92G1DF070BE12 Gas Furnace, 120 V, 340 to 1380 cfm, 1/2 hp, 92.1 % AFUE, Downflow
- Manufacturer: Allied Air Enterprises LLC
- Brand Name: Ducane™
- Part Number: CON 92G1DF070BE12
- MPN: 92G1DF070BE12
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
Ducane™ Gas Furnace, Series: 92G1E Series, Input BTU Rating: 66000 Btu/hr, Output BTU Rating: 63000 Btu/hr, 120 V, 340 to 1380 cfm, 1/2 hp, 92.1 % AFUE Rating, 1 ph Phase, 60 Hz, 1 Stages, Downflow, 1/2 in Connection, Blower Size: 10 x 8 in, 33 in H x 17-1/2 in W x 28-1/2 in D Cabinet, Constant Torque/High-Efficiency Motor, Vent, Ducted or Ductless: Direct, Indirect Vent, 15 A Fuse Rating, Tonnage: 3 ton, 40 VA Transformer, 0.1 to 0.8 in-WC, 40 to 70 deg F Temperature Rise, Additional Information: 6.8 FLA Nominal, Aluminized Steel Primary Heat Exchanger, Stainless Steel Secondary Heat Exchanger
| AFUE Rating | : | 92.1 % |
| Additional Information | : | 6.8 FLA Nominal, Aluminized Steel Primary Heat Exchanger, Stainless Steel Secondary Heat Exchanger |
| Blower Size | : | 10 x 8 in |
| CFM Rating | : | 340 to 1380 cfm |
| Cabinet Dimensions | : | 33 in H x 17-1/2 in W x 28-1/2 in D |
| Configuration | : | Downflow |
| Connection Size | : | 1/2 in |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 15 A |
| HP Rating | : | 1/2 hp |
| Input BTU Rating | : | 66000 Btu/hr |
| Motor Type | : | Constant Torque/High-Efficiency |
| Number of Stages | : | 1 |
| Output BTU Rating | : | 63000 Btu/hr |
| Phase | : | 1 ph |
| Pressure Rating | : | 0.1 to 0.8 in-WC |
| Series | : | 92G1E Series |
| Temperature Rise | : | 40 to 70 deg F |
| Tonnage | : | 3 ton |
| Transformer Rating | : | 40 VA |
| Vent, Ducted or Ductless | : | Direct, Indirect Vent |
| Voltage Rating | : | 120 V |
- 92% AFUE efficiency rating means you can enjoy significant energy savings
- The constant-torque blower motor produces even temperatures throughout your home, using up to a third less energy than a conventional blower and greatly reducing your energy bills
- Powerful single-stage motor delivers years of dependable comfort and helps reduce heating costs compared to older, less efficient furnaces
- Robust aluminized steel heat exchanger is crimped, not welded, for increased durability and safety when burners are ignited
- Anti-vibration blower assembly eliminates loud startup and shutdown noises for peaceful, quiet operation
- 10-year limited warranty on parts and a limited lifetime warranty on the heat exchanger (with registration) offer added peace of mind
