Ducane™ 4HP17L42P CON 4HP17L42P
Ducane™ 4HP17L42P Split System Heat Pump, 208-230 V, 25.9 A, 40500 Btu/hr BTU, 1/3 hp, 1 ph, Steel
- Manufacturer: Allied Air Enterprises LLC
- Brand Name: Ducane™
- Part Number: CON 4HP17L42P
- MPN: 4HP17L42P
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
Ducane™ Split System Heat Pump, Model: 4HP17L, 208-230 V, 25.9 A, 1/3 hp Rating, 60 Hz, 1 ph, 825 rpm Rotational Speed, 40500 Btu/hr, 12.2 EER, 17 SEER, HSPF: 9.2, Scroll Compressor, R-410A, 3/8 in Liquid Line, 7/8 in Suction Line, 40 A Fuse, 42 ton Tonnage, 78 dBA, 1 Stage, Grommet Mount, Steel, Galvanized, 0 to 125 deg F, 38 in H x 32-1/4 in W x 32-1/4 in D, Additional Information: High Efficiency, 18.6 A Rated Load, 110 A Locked Rotor, 2.6 A Full Load
| Additional Information | : | High Efficiency, 18.6 A Rated Load, 110 A Locked Rotor, 2.6 A Full Load |
| Amperage Rating | : | 25.9 A |
| BTU Rating | : | 40500 Btu/hr |
| Compressor Type | : | Scroll |
| Dimensions | : | 38 in H x 32-1/4 in W x 32-1/4 in D |
| EER Rating | : | 12.2 |
| Finish | : | Galvanized |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 40 A |
| HP Rating | : | 1/3 hp |
| HSPF Rating | : | 9.2 |
| Liquid Line Size | : | 3/8 in |
| Material | : | Steel |
| Model | : | 4HP17L |
| Mounting Type | : | Grommet |
| Number of Stages | : | 1 |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| Rotational Speed | : | 825 rpm |
| SEER Rating | : | 17 |
| Sound Level | : | 78 dBA |
| Suction Line Size | : | 7/8 in |
| Temperature Rating | : | 0 to 125 deg F |
| Tonnage | : | 42 ton |
| Voltage Rating | : | 208-230 V |
- Up to 16.2 SEER2 and 7.5 HSPF2 efficiency ratings
- ENERGY STAR® certification means you could be eligible for money-saving rebates
- Omniguard® Total Corrosion Protection Technology helps protect against corrosive elements extending the life of your unit for years to come
- Quiet Shift™ technology reduces operating sounds when the unit goes into defrost mode to remove frost and ice buildup, so you get better performance with minimal noise and less maintenance
- Powerful single-stage motor delivers years of dependable comfort and helps reduce heating costs compared to older, less efficient furnaces
- Dual-Fuel system offers an ideal combination of energy sources, electric and gas, pairing a heat pump and matching gas furnace together to maintain comfort
- Permanently lubricated condenser fan motor needs no annual maintenance
- 10-year limited warranty on the compressor and parts means lasting peace of mind
