ARMSTRONG AIR® 4SHP16LS124P ARM 4SHP16LS124P
ARMSTRONG AIR® 4SHP16LS124P Heat Pump Condenser, 2 ton, 22000 Btu/hr BTU, 208/240 VAC, 13.6 A, 1/6 hp, 1 ph Phase
- Manufacturer: Allied Air Enterprises LLC
- Brand Name: ARMSTRONG AIR®
- Part Number: ARM 4SHP16LS124P
- MPN: 4SHP16LS124P
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
The ARMSTRONG AIR® full line of heat pumps is the perfect example of what happens when you set out to be the best. Quiet, energy efficient and made with pride by people who know quality, ARMSTRONG AIR® units represent the premium choice of HVAC professionals throughout North America.
ARMSTRONG AIR® Heat Pump Condenser, 4SHP16LS Model, 208/240 VAC Voltage Rating, 13.6 A Amperage Rating, 1/6 hp Rating, 60 Hz Frequency Rating, 1 ph Phase, 825 rpm Rotational Speed, 22000 Btu/hr BTU Rating, 13 EER Rating, 16 SEER Rating, 9.5 HSPF Rating, High-Efficiency Scroll Compressor Type, R-410A Refrigerant Type, 3/8 in Liquid Line Size, 3/4 in Suction Line Size, 2 ton Tonnage, 76 dBA Sound Level, 2 Number of Stages, Grommet Mounting Type, Steel, Baked Polyester Painted, 0 to 125 deg F Temperature Rating, 33-3/4 in H x 29-1/4 in W x 35-1/4 in D Dimensions
| Amperage Rating | : | 13.6 A |
| BTU Rating | : | 22000 Btu/hr |
| Compressor Type | : | High-Efficiency Scroll |
| Dimensions | : | 33-3/4 in H x 29-1/4 in W x 35-1/4 in D |
| EER Rating | : | 13 |
| Finish | : | Baked Polyester Painted |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/6 hp |
| HSPF Rating | : | 9.5 |
| Liquid Line Size | : | 3/8 in |
| Material | : | Steel |
| Model | : | 4SHP16LS |
| Mounting Type | : | Grommet |
| Number of Stages | : | 2 |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| Rotational Speed | : | 825 rpm |
| SEER Rating | : | 16 |
| Sound Level | : | 76 dBA |
| Suction Line Size | : | 3/4 in |
| Temperature Rating | : | 0 to 125 deg F |
| Tonnage | : | 2 ton |
| Voltage Rating | : | 208/240 VAC |
- Grommet-mounted compressor for quiet operation
- Heavy-duty compressor sound blanket for quiet operation
- Internally protected against high temperature motor overload conditions
- Full metal louvered panel with two screws to remove for ease of coil cleaning and service
- Corner-mounted controls for easy service
- Rounded corners for safety and attractive, clean appearance
- Baked polyester paint finish over galvanized steel for maximum durability
- Removable PVC-coated wire fan discharge grill
- 45 deg offset gauge ports for easy service
- Removable service panel for internal access
- Omniguard™ total corrosion protection technology designed coil
- Enhanced tube and fin coil design featuring MHT™ Technology
- Lanced fins for maximum heat transfer
- Factory tested for leak-proof construction
- Raised coil prevents debris from impeding airflow
- Factory installed crankcase heater
- Factory installed high and low pressure switches
- Thread-on pressure switches with Schrader core for simple, quick replacement
- Filter drier shipped loose for installation flexibility
- Fan orifice for smoother airflow and sound level reduction
