AMERISTAR® A5PG3024A1060A A5PG3024^1060^
AMERISTAR® Ovation Series A5PG3024A1060A Gas/Electric Packaged Unit, 24000 Btu/hr Cooling, 60000 Btu/hr Heating Input
- Manufacturer: Trane International Inc
- Brand Name: AMERISTAR®
- Part Number: A5PG3024^1060^
- MPN: A5PG3024A1060A
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
AMERISTAR® Gas/Electric Packaged Unit, 24000 Btu/hr Cooling, 60000 Btu/hr Heating Input BTU Rating, 208-230 V Voltage Rating, 16 A Amperage Rating, 1.98 kW Wattage, 1/12 hp Rating, 810 rpm Rotational Speed, 60 Hz Frequency Rating, 3 ph Phase, Scroll Compressor Type, 820 cfm Rating, 81 % AFUE Rating, 2 ton Tonnage, R-454B Refrigerant Type, 66.6 dB Decibel Rating, Roof Mounting Type, Electronic Ignition Type, Direct Drive Type, 13.32 sq-ft Face Area Outdoor, 2.7 sq-ft Face Area Indoor Coil Rating, 3/4 in FNPT Drain Connection, 25 A Fuse Rating, Steel, Enamel, 30 to 60 deg F Temperature Rating, 36 in H x 49 in W x 42 in D Dimensions
| AFUE Rating | : | 81 % |
| Amperage Rating | : | 16 A |
| CFM Rating | : | 820 cfm |
| Coil Rating | : | 13.32 sq-ft Face Area Outdoor, 2.7 sq-ft Face Area Indoor |
| Compressor Type | : | Scroll |
| Decibel Rating | : | 66.6 dB |
| Dimensions | : | 36 in H x 49 in W x 42 in D |
| Drain Connection | : | 3/4 in FNPT |
| Drive Type | : | Direct |
| Finish | : | Enamel |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 25 A |
| HP Rating | : | 1/12 hp |
| Ignition Type | : | Electronic |
| Input BTU Rating | : | 24000 Btu/hr Cooling, 60000 Btu/hr Heating |
| Material | : | Steel |
| Mounting Type | : | Roof |
| Phase | : | 3 ph |
| Refrigerant Type | : | R-454B |
| Rotational Speed | : | 810 rpm |
| Temperature Rating | : | 30 to 60 deg F |
| Tonnage | : | 2 ton |
| Voltage Rating | : | 208-230 V |
| Wattage | : | 1.98 kW |
Submittal
