| AFUE Rating | : | 80 % |
| Amperage Rating | : | 9.2 A |
| Blower Size | : | 11 x 8 in |
| Cabinet Dimensions | : | 34 in H x 17-1/2 in W x 28-3/4 in D |
| Configuration | : | Downflow, Horizontal, Upflow |
| Frequency Rating | : | 60 Hz |
| Fuel Type | : | LP Gas, Natural Gas |
| Fuse Rating | : | 15 A |
| HP Rating | : | 3/4 hp |
| Ignition Type | : | SiNi |
| Input BTU Rating | : | 80000 Btu/hr |
| Motor Type | : | CTM |
| Number of Speeds | : | 9 |
| Number of Stages | : | 1 |
| Output BTU Rating | : | 65100 Btu/hr |
| Phase | : | 1 ph |
| Rotational Speed | : | 1050 rpm |
| Series | : | S8B1 Series |
| Temperature Rise | : | 30 to 60 deg F |
| Tonnage | : | 6 ton |
| Vent Size | : | 4 in |
| Vent, Ducted or Ductless | : | Vent |
| Voltage Rating | : | 120 V |
