| Amperage Rating | : | 2 A |
| BTU Rating | : | 36000 Btu/hr |
| CFM Rating | : | 600 to 1800 cfm |
| Configuration | : | 4-Way, Multi-Position |
| Connection Type | : | Brazed |
| Dimensions | : | 45-1/8 in H x 18-1/2 in W x 21-1/8 in D |
| Finish | : | Galvanized |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/3 hp |
| Liquid Line Size | : | 3/8 in |
| Material | : | Metal |
| Motor Type | : | PSC |
| Nominal Capacity | : | 3 ton |
| Number of Speeds | : | 3 |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| Rotational Speed | : | 825 rpm |
| SEER Rating | : | 14 |
| Series | : | A4AH4 Series |
| Suction Line Size | : | 3/4 in |
| Voltage Rating | : | 208/230 V |
