American Standard® 5A6H4060A1000A 5A6H4060^1000^
American Standard® Eclipse Series 5A6H4060A1000A Heat Pump, 5 ton, 60000 Btu/hr BTU, 208-230 V, 33 A, 1-1/3 hp
- Manufacturer: Trane International Inc
- Brand Name: American Standard®
- Part Number: 5A6H4060^1000^
- MPN: 5A6H4060A1000A
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
American Standard® Heat Pump, Silver Series, Silver 14 Model, 208-230 V Voltage Rating, 33 A Amperage Rating, 1-1/3 hp Rating, 60 Hz Frequency Rating, 1 ph Phase, 850 rpm Rotational Speed, 60000 Btu/hr BTU Rating, 4992 cfm Rating, 14 SEER Rating, 7.8 HSPF Rating, Scroll Compressor Type, R-454B Refrigerant Type, 50 A Fuse Rating, 30.8 sq-ft Face Area Coil Rating, 5 ton Tonnage, 72 dBA Sound Level, 1 Number of Stages, 45 in H x 34 in W x 37 in D Dimensions, ECM Blower Motor Additional Information
| Additional Information | : | ECM Blower Motor |
| Amperage Rating | : | 33 A |
| BTU Rating | : | 60000 Btu/hr |
| CFM Rating | : | 4992 cfm |
| Coil Rating | : | 30.8 sq-ft Face Area |
| Compressor Type | : | Scroll |
| Dimensions | : | 45 in H x 34 in W x 37 in D |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 50 A |
| HP Rating | : | 1-1/3 hp |
| HSPF Rating | : | 7.8 |
| Model | : | Silver 14 |
| Number of Stages | : | 1 |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-454B |
| Rotational Speed | : | 850 rpm |
| SEER Rating | : | 14 |
| Series | : | Silver Series |
| Sound Level | : | 72 dBA |
| Tonnage | : | 5 ton |
| Voltage Rating | : | 208-230 V |
- This heat pump helps you save up to 47 percent on your heating and cooling energy usage while reducing greenhouse gas emissions
- Provides more eicient and reliable cooling, thanks to its Spine Fin™ coil and Duration™ compressor
- Pair your heat pump with a gas furnace to create your own hybrid system. Once your heat pump reaches its heating capacity, your gas furnace steps in to keep you comfortable for as long as you need
