American Standard® 5A6H4048A1000A 5A6H4048^1000^
American Standard® Silver Series Silver 14 5A6H4048A1000A Heat Pump, 208-230 V, 25 A, 48000 Btu/hr BTU, 1-1/3 hp
- Manufacturer: Trane International Inc
- Brand Name: American Standard®
- Part Number: 5A6H4048^1000^
- MPN: 5A6H4048A1000A
- Min. Order Qty: 1
- Qty. Interval: 1 Sign In for Availability
-
Price:
American Standard® Heat Pump, Silver Series, Model: Silver 14, 208-230 V, 25 A, 1-1/3 hp, 60 Hz, 1 ph Phase, 850 rpm Rotational Speed, 48000 Btu/hr, 4992 cfm, 14 SEER, 7.8 HSPF, Scroll Compressor, R-454B Refrigerant, 40 A Fuse Rating, 30.8 sq-ft Face Area Coil, Tonnage: 4 ton, 70 to 72 dBA Sound Level, 1 Stages, 45 in H x 34 in W x 37 in D, Additional Information: ECM Blower Motor
| Additional Information | : | ECM Blower Motor |
| Amperage Rating | : | 25 A |
| BTU Rating | : | 48000 Btu/hr |
| CFM Rating | : | 4992 cfm |
| Coil Rating | : | 30.8 sq-ft Face Area |
| Compressor Type | : | Scroll |
| Dimensions | : | 45 in H x 34 in W x 37 in D |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 40 A |
| HP Rating | : | 1-1/3 hp |
| HSPF Rating | : | 7.8 |
| Model | : | Silver 14 |
| Number of Stages | : | 1 |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-454B |
| Rotational Speed | : | 850 rpm |
| SEER Rating | : | 14 |
| Series | : | Silver Series |
| Sound Level | : | 70 to 72 dBA |
| Tonnage | : | 4 ton |
| Voltage Rating | : | 208-230 V |
- This heat pump helps you save up to 47 percent on your heating and cooling energy usage while reducing greenhouse gas emissions
- Provides more eicient and reliable cooling, thanks to its Spine Fin™ coil and Duration™ compressor
- Pair your heat pump with a gas furnace to create your own hybrid system. Once your heat pump reaches its heating capacity, your gas furnace steps in to keep you comfortable for as long as you need
